Balanced Cost-Performance Workhorse Nylon
Seven standard PA6 formulations covering economy structural, premium certified, custom OEM, high-temperature, toughened cold-resistant and food-contact applications.
High-value economy PA6 with 35% glass fiber. Tensile 138 MPa, Izod 15 kJ/m². Best for structural brackets, pulleys and cost-driven industrial components.
Fully tailor-made PA6 compound. Choose GF 10%-50%, FR V0/V2, color RAL, UV stabilizer, impact modifier and processing aid package. Sample in 5 days.
Heat-stabilized PA6/66 alloy. HDT @1.8 MPa up to 210°C. Designed for under-hood automotive parts, motor housings and continuous elevated-temperature use.
Elastomer-toughened PA6 for low-temperature environments. Notched Izod ≥ 50 kJ/m² at -30°C. Ideal for outdoor power tools, ski bindings and cold-climate parts.
FDA 21 CFR 177.1500 and EU 10/2011 food-contact compliant PA6 with 30% GF. Natural color, low migration. Suitable for food processing parts and kitchen appliances.
Well-balanced standard PA6 reinforced with 30% chopped glass fiber. Consistent batch-to-batch mechanicals for high-volume structural projects.
Premium PA6 with 30% GF. Tensile 160+ MPa, tight ±3% property tolerance. Fully certified grade for critical structural and cosmetic Class-A applications.
Every batch of Juhai PA6 is compounded in-house on twin-screw lines with strict ISO lab testing to ensure lot-to-lot consistency and reproducible part performance.
In-house material scientists formulate every PA6 grade — from base-resin selection to glass-fiber sizing compatibility.
Three co-rotating twin-screw compounding lines (65/75/95 mm) with underwater pelletizing — 20,000 MT annual PA6 capacity.
Full ISO mechanical, thermal, physical test lab on site — every lot tested for tensile, impact, HDT, MVR and moisture before release.
All PA6 grades guaranteed within ±5% of quoted datasheet values. CpK > 1.33 on key mechanical properties for all standard grades.
PA6 offers better processability and lower cost; PA66 delivers higher heat resistance. Choose PA6 when cost, flow and surface finish matter more than extreme HDT. Read our in-depth PA6 vs PA66 comparison guide →
| Property | Standard PA6 GF30 | Standard PA66 GF30 |
|---|---|---|
| Relative Material Cost | ✓ Lower (-15 to -22%) | Higher |
| Water Absorption (24 h, ISO 62) | ✓ ~1.0% (slightly better dim. stability after conditioning) | ~1.2% |
| HDT @ 1.82 MPa (ISO 75/Af) | ~175–190°C | ✓ ~240–250°C |
| Notched Izod Impact @ 23°C | ✓ Higher toughness (12–18 kJ/m²) | 10–14 kJ/m² (more brittle) |
| Injection Molding Cycle Time | ✓ 10–20% faster (lower Tm & faster crystallization) | Longer cycle |
Pick the right glass-fiber loading for your stiffness / impact / shrinkage tradeoff. Each grade links to the matching product detail page.
| PA6 Grade by GF% | Tensile Strength (ISO 527) | HDT @ 1.82 MPa | Mold Shrinkage (Flow) | Notched Izod @ 23°C | Typical Applications |
|---|---|---|---|---|---|
| PA6 GF0 (Unreinforced) | 70–80 MPa | 70–90°C | 0.9–1.3% | 80+ kJ/m² (no break) | Thin-wall snap-fit parts, cable ties, textile components, gear wheels |
| PA6 GF15 | 95–110 MPa | 135–150°C | 0.55–0.75% | 25–35 kJ/m² | Low-load housings, appliance covers, consumer goods, furniture parts |
| PA6 GF25 | 120–135 MPa | 165–178°C | 0.40–0.50% | 18–25 kJ/m² | Medium-load structural brackets, auto interior clips, power tool bodies |
| PA6 GF30 (Most Popular) | 145–160 MPa | 175–190°C | 0.35–0.45% | 14–20 kJ/m² | Connectors, appliance frames, auto secondary structure, industrial housings |
| PA6 GF35 | 135–145 MPa | 185–195°C | 0.30–0.40% | 12–17 kJ/m² | Structural pulleys, conveyor brackets, cost-driven industrial parts |
| PA6 GF50 (High-Modulus) | 185–205 MPa | 205–215°C | 0.18–0.25% | 9–13 kJ/m² | Ultra-stiff structural frames, low-warpage precision parts, bearing cages |
For high-volume medium-load structural applications, our BFE06 and GBA35 economy PA6 grades deliver 90%+ of premium PA6 GF30 mechanical performance at a significantly lower material cost.
Below are typical composite property ranges across our PA6 GF15–GF50 product family. Exact grade-specific values are on each product page or in the downloadable PDF datasheet — request via the form at the bottom.
| Property | Test Standard | Typical Range (PA6 GF15–GF50) |
|---|---|---|
| Tensile Strength | ISO 527 | 95 – 205 MPa |
| Tensile Modulus | ISO 527 | 3,800 – 12,500 MPa |
| Elongation at Break | ISO 527 | 1.5 – 8.0 % |
| Flexural Strength | ISO 178 | 140 – 310 MPa |
| Flexural Modulus | ISO 178 | 3,200 – 10,800 MPa |
| Notched Izod Impact, 23°C | ISO 180/1A | 9 – 35 kJ/m² |
| Unnotched Izod Impact, 23°C | ISO 180/1U | 35 – 110 kJ/m² |
| Charpy Notched Impact, 23°C | ISO 179/1eA | 8 – 28 kJ/m² |
| Water Absorption (24 h, 23°C) | ISO 62 | 1.0 % (conditioned PA6 GF30 reference) |
| Property | Test Standard | Typical Range (PA6 GF15–GF50) |
|---|---|---|
| Heat Deflection Temperature @ 1.82 MPa | ISO 75/Af | 135 – 215 °C |
| Heat Deflection Temperature @ 0.45 MPa | ISO 75/Bf | 155 – 225 °C |
| Vicat Softening Temperature (B/50) | ISO 306 | 170 – 220 °C |
| Melting Point (DSC Peak) | ISO 11357 | 218 – 225 °C |
| Coefficient of Linear Thermal Expansion (flow) | ISO 11359-2 | 2.0 – 5.0 × 10⁻⁵ °C⁻¹ |
| Continuous Use Temperature (UL 746B, electrical) | UL 746B | 105 – 125 °C (evaluated) |
| Property | Test Standard | Typical Range (PA6 GF15–GF50) |
|---|---|---|
| Density | ISO 1183 | 1.20 – 1.54 g/cm³ |
| Melt Volume-Flow Rate (MVR) 275°C / 5.0 kgf | ISO 1133 | 15 – 60 cm³/10 min |
| Mold Shrinkage — Flow Direction | ISO 294-4 | 0.20 – 0.75 % |
| Mold Shrinkage — Cross Direction | ISO 294-4 | 0.70 – 1.40 % |
| Water Absorption (Equilibrium, 23°C / 50% RH) | ISO 62 | 2.5 – 3.2 % |
| Surface Resistivity | IEC 60093 | 1 × 10¹³ – 1 × 10¹⁵ Ω/sq |
| Dielectric Strength (2 mm, short-time) | IEC 60243-1 | 17 – 22 kV/mm |
| Comparative Tracking Index (CTI) | IEC 60112 | CTI 0 / 1 (≥ 600 V) for CTI grades |
Standard PA6 injection molding parameters. Always pre-dry PA6 to < 0.08% moisture content before processing to prevent splay marks and hydrolytic chain scission during melt.
| Process Parameter | Recommended Value / Range | Notes |
|---|---|---|
| Pre-Drying | 80 °C × 4 hours (dehumidifying dryer) | Target moisture < 0.08%. Ambient air drying is insufficient for PA6. |
| Barrel Zone 1 (Rear) | 230 – 240 °C | Lower rear temp minimizes GF fiber breakage in feed zone. |
| Barrel Zone 2 (Middle) | 245 – 255 °C | |
| Barrel Zone 3 (Front) | 255 – 270 °C | |
| Nozzle Temperature | 250 – 265 °C | Slightly lower than front zone to prevent drooling. |
| Mold Temperature | 60 – 90 °C | 80–90°C recommended for best surface finish and GF wet-out. |
| Injection Pressure | 80 – 140 MPa | Higher for thin walls and higher GF loadings. |
| Holding Pressure | 50 – 80% of injection pressure | Hold time 10–25 s; scale with wall thickness. |
Modified PA6 compounds are used wherever a balance of mechanical strength, heat resistance, toughness and processability is required at a competitive material cost.
Dashboard structural brackets, HVAC housings, door module carriers, seat adjuster components, cable management clips. PA6 GF25-GF30.
Washing machine tub internals, dryer impellers, coffee machine brew groups, mixer motor housings, iron soleplate carriers. PA6 GF20-GF35.
Gears, bearing cages, wear plates, conveyor rollers, pulley bodies, pump housings, valve components. PA6 GF30-GF50 by load.
Drill housings, angle-grinder motor cans, gear-case covers, chainsaw sprockets, impact-wrench frames. Toughened PA6 for cold-climate outdoor tools.
Ski bindings, inline skate frames, bicycle pedals and derailleurs, rock-climbing hardware, fishing reels. High-impact toughened PA6 grades.
Wire-to-board connectors, relay bases, coil bobbins, terminal blocks, sensor housings. CTI 600V + flame-retardant V0 PA6 options available.
Conveyor guides, food-grade gear wheels, slicer components, commercial-kitchen appliance internals. FDA-compliant PA6 GBC30 natural-color grade.
Loom shuttle parts, yarn-guide rollers, sewing machine components, monofilament extruded parts. Unreinforced and GF15 PA6 grades.
| Standard Export Packaging | 25 kg heat-sealed kraft / PE composite bags with inner aluminum moisture barrier (keeps PA6 dry 24+ months). |
|---|---|
| Pallet Configuration | 40 bags per 1,000 kg (1 MT) standard export wooden pallet; stretch-wrapped + 4 corner protectors. |
| Minimum Order Quantity (MOQ) | 1,000 kg (1 pallet / 40 bags × 25 kg) for all standard PA6 grades in stock colors (black / natural). |
| Stock Lead Time (Standard Grades) | 3 – 5 working days after T/T deposit or L/C confirmation (EXW Ningbo / FOB Ningbo). |
| Custom Color or Custom Formulation MOQ | 5,000 kg (5 pallets). Samples ready in 5–7 working days; bulk production 10–15 days. |
| Container Loading | 20 ft FCL: ~20,000 kg (20 pallets × 1 MT). 40 ft HC: ~27,000 kg (27 pallets × 1 MT). |
| Documents Supplied per Shipment | Commercial Invoice · Packing List · Bill of Lading / AWB · Certificate of Origin · Certificate of Conformance (CoC) with lot test data · ROHS & REACH compliance letter · MSDS (on request). |
Most common technical and commercial questions from injection molders and OEM buyers about modified PA6 compounds.
Recommended standard drying for all PA6 grades: 80°C for 4 hours in a dehumidifying (desiccant) dryer, to achieve final pellet moisture content below 0.08% (800 ppm). A hopper dryer without desiccant (ambient-air dryer) is NOT sufficient for PA6 — it will at best reach 0.20% moisture, which causes splay marks, hydrolytic degradation and 10–15% tensile loss in the molded part. For high-humidity climates (RH > 65%), extend drying time to 6 hours or double-check moisture with a portable PA moisture analyzer. For opened bags exposed > 48 hours, re-dry at 90°C for 5 hours before re-processing.
Yes, we produce several flame-retardant (FR) PA6 grades, both halogen-free red-phosphorus based and halogen-containing brominated systems depending on your requirements. Standard catalog FR PA6 grade FTF02-FRV0 is UL94 V0 rated at 0.8 mm with GF25 content and GWIT 775°C glow-wire performance for electrical connector applications. Non-halogen (eco-friendly) PA6 FR V0 with GF30 is also available under FTF02-FRV0-HF. FR PA6 grades carry a MOQ of 2,000 kg for standard black FRV0. Custom CTI 600V + FR V0 + GF30 combination can be quoted on request — tell us your UL file target and our R&D will match the formulation.
The standard MOQ for bulk export orders is indeed 1,000 kg (one full pallet). However, we do support genuine material-evaluation trial batches smaller than 1 ton at a modest per-kilogram premium (typically +15% on the standard unit price). We can also ship our free 2 kg test sample first for you to run small-scale molding trials on your own injection machine before committing to a 1-ton pallet. Trial batches of 100–500 kg ship in 2–3 working days if the grade is in stock, and are packaged either as full 25 kg bags or (for <100 kg) smaller 5 kg sample bags on request. Ask our sales engineer for the trial-batch quote during your inquiry.
Yes, absolutely — every single shipment (including 1-pallet MOQ orders) includes a signed Certificate of Conformance (CoC / Material Test Report) with the actual tested mechanical and physical properties from that exact production lot, not generic datasheet values. Our standard CoC includes: lot number & date, tensile strength, tensile modulus, flexural strength, notched Izod impact, HDT @ 1.82 MPa, MVR, density, moisture and color dE vs master — all tested per ISO standard in our own in-house ISO lab. We also include the ROHS 2.0 and REACH SVHC compliance letter, plus MSDS and Certificate of Origin on request. For FDA food-contact grades (GBC30 series), the CoC additionally confirms FDA 21 CFR 177.1500 and EU 10/2011 compliance of the lot.
Fill in the form below. Our PA6 technical sales engineer will reply within 8–24 hours with exact pricing, stock status, sample availability and the correct grade recommendation for your application.
PA6 max HDT tops out around 215°C. For continuous operating temperatures above 120°C or HDT targets above 200°C under load, check our PA66 range with HDT up to 250°C @ 1.82 MPa and tensile 190+ MPa.
👉 See Our PA66 Grades — Higher Heat / Higher Strength
